Knowledge Graph Data structure

Iggytop is built on top of BioCypher by providing a set of adapters as well as an ontology to generate knowledge graphs for TCR-epitope datasets.

Data Generation Process

The generation process relies on the create_knowledge_graph.py script. The pipeline follows these key steps:

1. Source Data Harmonization

Similar to the tabular data structure, IggyTop leverages BioCypher adapters to read and harmonize data:

• Mapping: Source formats are mapped to internal registry keys.

• Gene Normalization: V(D)J genes are aligned with IMGT standards.

• Sequence Processing: Harmonization of CDR3 and epitope sequences.

The harmonization is based on tidytcells wherever possible and tries to follow AIRR and IMGT standards.

2. Graph Construction

Instead of just stacking tables, the pipeline uses the BioCypher framework to:

• Instantiate Nodes based on the Ontology.

• Create Edges representing the associations between Nodes.

• The resulting graph can be exported to various formats (Neo4j, NetworkX, GraphML).

3. Processing Options

Graph construction

Users can customize the graph generation using several flags in create_knowledge_graph.py:

• Receptor Types: Specify which receptors to include (e.g., --receptors TCR BCR).

• Adapter Selection: Choose specific databases to include in the graph.

• 10X Data Filtering: To address concerns regarding the confidence of some large-scale datasets, users can use the --filter-10x flag to exclude data originating from the 10X Genomics dataset. This will remove records stored in the source databases which stem from this dataset. This flag is also set for the released dataset (deduplicated_anndata.h5ad)

  Note The ITRAP dataset contains data from this dataset. The ITRAP data are the (5k out of 60k) pairs that have passed the ITRAP qc filtering and are therefore considered high quality. These records are not filtered out. If you want to completely exclude 10X data, consider excluding ITRAP from the pipeline.

Graph queries

Follow the instructions in the readme to start the docker container running a neo4j instance with the full knowledge graph. The knowledge graph can then be explored using Neo4j and Cypher see here for more information on how to use Neo4j.

Knowledge Graph

Design Choices

Ontology

BioCypher uses the Biolink ontology and allows custom modifications. This is done using configuration files. The ontology used for iggytop is defined in config/schema_config.yaml. This includes defining the node and edge types and their relationships (hierarchy).

entity
├── association
│   ├── binding to database association
│   ├── binding to pmhc association
│   ├── binding to pmid association
│   ├── binding to receptor complex association
│   ├── chain to gene association
│   ├── epitope to antigen association
│   ├── pmhc to epitope association
│   ├── pmhc to mhc association
│   └── receptor complex to chain association
└── named thing
    ├── PMID
    ├── binding
    ├── biological entity
    │   ├── antigen
    │   ├── gene
    │   │   └── immune receptor gene
    │   │       ├── j_gene
    │   │       └── v_gene
    │   ├── pmhc
    │   ├── polypeptide
    │   │   ├── epitope
    │   │   ├── immune receptor chain
    │   │   │   ├── chain_1
    │   │   │   └── chain_2
    │   │   └── mhc
    │   └── receptor complex
    └── database

INFO:biocypher:
entity
├── association
│   ├── binding to database association
│   ├── binding to pmhc association
│   ├── binding to pmid association
│   ├── binding to receptor complex association
│   ├── chain to gene association
│   ├── epitope to antigen association
│   ├── pmhc to epitope association
│   ├── pmhc to mhc association
│   └── receptor complex to chain association
└── named thing
    ├── PMID
    ├── binding
    ├── biological entity
    │   ├── antigen
    │   ├── gene
    │   │   └── immune receptor gene
    │   │       ├── j_gene
    │   │       └── v_gene
    │   ├── pmhc
    │   ├── polypeptide
    │   │   ├── epitope
    │   │   ├── immune receptor chain
    │   │   │   ├── chain_1
    │   │   │   └── chain_2
    │   │   └── mhc
    │   └── receptor complex
    └── database

Node and Edge Types

The graph is organized as a hub-and-spoke hierarchy around a central binding node, which represents one reported TCR/BCR-epitope pairing:

• Each binding node has exactly one edge to a receptor complex node and exactly one edge to a pmhc node — together these identify which receptor was reported to recognize which peptide-MHC.

• The same pairing reported by several sources (e.g. the same complex-pmhc pairing appearing in both VDJDB and IEDB, or the same source citing multiple publications) collapses onto the same binding node: its ID is built from the receptor complex and pmhc content, deliberately excluding source/database/PMID. That shared node can then carry edges out to every database and PMID node that reported it, rather than one row per source.

• receptor complex and pmhc are themselves join nodes: a receptor complex links to its chain_1/chain_2 nodes, and a pmhc links to its epitope and mhc nodes. Because these nodes are shared (deduplicated) rather than duplicated per record, records with, e.g., the same V/J gene or the same epitope naturally converge on the same downstream nodes — this is how the graph surfaces similarities between receptors and epitopes across the whole dataset, rather than just stacking independent rows.

Nodes

Node	Parent type	Key properties
binding	named thing	complete, tissue
receptor complex	biological entity	complete
chain_1 (alpha/heavy), chain_2 (beta/light)	immune receptor chain → polypeptide	cdr3_aa, junction_aa, v_call, j_call, locus, organism, complete
v_gene, j_gene	immune receptor gene → gene	— (id-only reference nodes)
pmhc	biological entity	iedb_iri, MHC_class, MHC_gene_1, MHC_gene_2, mhc_present
epitope	polypeptide	epitope_sequence, iedb_iri, antigen_name
antigen	biological entity	antigen_species
mhc	polypeptide	MHC_class, MHC_gene_1, MHC_gene_2
database	named thing	version
PMID	named thing	pmid

Edges

Edge	Subject → Object
binding to receptor complex association	binding → receptor complex
binding to pmhc association	binding → pmhc
binding to database association	binding → database
binding to pmid association	binding → PMID
receptor complex to chain association	receptor complex → chain_1 / chain_2
chain to gene association	chain_1/chain_2 → v_gene / j_gene
pmhc to epitope association	pmhc → epitope
pmhc to mhc association	pmhc → mhc
epitope to antigen association	epitope → antigen

See config/schema_config.yaml for the full property/type definitions and the ontoweaver_mapping_*.yaml files (and ontoweaver_transformers.py) for exactly how each node’s ID and properties are built from the source table columns.

Output Formats and Availability

The knowledge graph can be exported in several ways:

1. Neo4j: Optimized for graph database queries. Check out the Docker guide in the README.

2. NetworkX / GraphML: Useful for Python-based graph analysis and visualization in tools like Cytoscape.

3. AIRR JSON: While natively a graph, output can be converted back to the AIRR format (tabular).

Bimonthly Releases

Knowledge graph exports as knowledge_graph.tar.gz are provided in bimonthly releases.

Creating Your Own Graph

You can run the graph generation locally to create custom subsets or use specific versions of the data:

python create_knowledge_graph.py --adapters VDJDB MCPAS --output-format networkx

Note that some parameters are defined in the config/biocypher_config.yaml. Check out this file and change it for more control (eg defining output type).
